Deedlock AEM0363 230v AC Electromagnetic Hold Open Magnet

£53.69
Availability: In stock
SKU
DEE-AEM0363



The new Deedlock Electromagnetic Hold Open Magnets are designed to be used in conjunction with any suitable fire alarm system.  They can hold open fire doors in most environments, particularly where the Disability Discrimination Act has to be considered.

The range is surface mounted in either a plastic or metal housing, fitted with an integral release button and supplied complete with an adjustable keeper plate and instructions.

The AEM0351/AEM0352 magnets can also be floor mounted using the AEM0362/AEM0363 magnets and can also be floor mounted using the AEMS004 floor mounting bracket (supplied seperately).

The 230v AC units includes a filter for EMC emissions, internal diodes dissipate any "back EMF" on switch-off, reducing wear at the control unit.



Features & Benefits

  • UK manufactured
  • Approved to BS EN1155: 1997 + A1:2003 and CE Marked by an independent test house
  • Integral part of any fire alarm system
  • 24v DC or 230v AC supply voltage
  • 200N Holding Force
  • IP 51 Rating
  • Spring loaded pin to give zero residual force
  • Adjustable Keeper Plate and instructions included
  • High quality cost effective package
  • Metal enclosures offer a robust construction
  • Easily mountable
  • AEM0362 & AEM0363 may be flush mounted into a deep single gang back box (not supplied).



Applications

  • The range is ideal for use in any public access areas, including Hospitals, Cinemas, Airports, Offices, Hotels and Residential Homes.



Technical Note

  • For linking the electromagnetic hold open magnets into a fire alarm system, they must be used with an auxiliary relay and a separate power supply unit.



Technical Details - Magnet

  • Door Holder Housing Size - Height 86mm x Width 86mm x Depth 61mm
  • Door HolderMagnet Surface Size - 38mm Diameter
  • Keeper Size - Height 69mm x Width 69mmm x Depth 45mm
  • Keepr Magnet Size - 46mm Diameter
  • Ambient Temperature - 0-35° Celcius
  • Current - 12mA
  • Voltage - 230v AC
  • Weight of Door Holder - 0.307 Kgs
  • Weight of Keeper - 0.128 Kgs
  • Casing - White Painted Metal



Technical Details - Bracket

  • Reference - AEMS004
  • Dimensions - Height 120mm x Width 100mm x Depth 50mm
  • Weight - 0.25 Kgs
  • Finish - White
  • Material - Metal
